Dashboard gadget

The chart module define a dashboard gadget that adds a panel to the workbench that displays custom statistics。

Manifest Example

chart:
    - key: basic-pie-chart
      resource: basic-pie-chart
      name: 类型占比
      description: 类型占比
      loadType: RemoteJs
      tabOrder: 1
      grid:
        w: 4
        h: 3
        minW: 1
        maxW: 12
        minH: 1

Properties

Name	Type	Required	Description
key	String	Yes	A key for the module, which other modules can refer to. Must be unique within the manifest.
resource	String	Yes	A reference to the static resources entry that gadget wants to display.
name	String	Yes	The name of the gadget, which is displayed at the top of the gadget.
description	String	No	The description of the gadget, which is displayed at the gadget list of the add gadget panel
loadType	Micro | Iframe | RemoteJs	Yes	The load resource type
tabOrder	String	No	Gadget class numbers. The class numbers of gadget in the same plugin should be the same.
grid	String	Yes	Gadget size. unit: grid. w: default width, h: default height, minW: min width, maxW: max width, minH: min height, maxH: max height
icon	String	Yes	The Base64 image of the icon that's display left to the name.
