Workflow PostFunction

The proxima:workflowPostFunction module can create a workflow post-processing function.

Configure post function through functions

Manifest example

modules:
  proxima:workflowPostFunction:
    - key: test-workflow-post-function
      title: Workflow Post Function
      description: Workflow Post Function
      function: workflow-post-function
  function:
    - key: workflow-post-function
      handler: workflow.runPostFunction

Configure post function through a custom UI

You can configure the post function in the validator through a custom UI interface. The following three pages need to be configured:

• create: The page for when the workflow post function is being created
• edit: The page for when the workflow post function is being edited
• view: The page for displaying the workflow post function

On the create and edit pages, you need to save the configuration information through the handleWorkflowConfigChange API.

manifest例子

modules:
  proxima:workflowPostFunction:
    - key: my-workflow-post-function
      title: Configure Workflow Transition Validator
      description: Custom workflow validator
      create:
        route: /workflow-post-function-create
      edit:
        route: /workflow-post-function-edit
      view:
        route: /workflow-post-function-view
      resource: main
      loadType: Micro
resources:
  - key: main
    path: /dist

Configure data

Through the handleWorkflowConfigChange method, you can record configuration data in the workflow

import { Input } from 'antd';

const WorkflowValidatorCreatePage = (props: any) => {
  const { context } = props;
  const handleWorkflowConfigChange = context?.modal?.handleWorkflowConfigChange;

  const onChange = (key, value) => {
    handleWorkflowConfigChange({ [key]: value });
  };

  return (
    <div>
      <div>label1：</div>
      <Input onChange={e => onChange('name1', e.target.value)} />
      <div>label2：</div>
      <Input onChange={e => onChange('name2', e.target.value)} />
    </div>
  );
};

export default WorkflowValidatorCreatePage;

Function script

workflow.ts

// The input parameters are as follows
export interface PostFunctionPayload {
  workflowId: string; // Workflow ID
  transition: string; // Transition action name
  currentState: string; // Current state name
  itemId: string; // Item ID
}

export const runPostFunction = ({ payload } : { payload: PostFunctionPayload }) => {
  const { workflowId, transition, currentState, itemId } = payload;
  // do something
};
